دیتاشیت STM32G431CBT6
مشخصات دیتاشیت
| نام دیتاشیت | STM32G431zzzz Datasheet |
|---|---|
| حجم فایل | 2769.66 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 200 |
دانلود دیتاشیت STM32G431zzzz Datasheet |
STM32G431zzzz Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- EEPROM: -
- CPU Core: ARM-MSeries
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 32KB
- Watchdog: Yes
- ADC (Bit): 12bit
- DAC (Bit): 12bit
- Datasheet: STMicroelectronics STM32G431CBT6
- PWM (Bit): -
- Real-Time Clock: -
- CPU Maximum Speed: 170MHz
- GPIO Ports Number: 38
- Low-Voltage Detect: Yes
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: DMA;PWM
- Program Memory Type: FLASH
- Direct Memory Access: Yes
- Program Storage Size: 128KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 1.71V~3.6V
- Infrared Data Association: Yes
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: LQFP-48(7x7)
- Manufacturer: STMicroelectronics
- Series: STM32G4
- Packaging: Tray
- Part Status: Active
- Core Processor: ARM® Cortex®-M4F
- Core Size: 32-Bit
- Speed: 170MHz
- Connectivity: CANbus, I²C, IrDA, LINbus, SPI, UART/USART
- Peripherals: Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT
- Number of I/O: 38
- Program Memory Size: 128KB (128K x 8)
- EEPROM Size: -
- Voltage - Supply (Vcc/Vdd): 1.71V ~ 3.6V
- Data Converters: A/D 17x12b; D/A 4x12b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 48-LQFP
- Supplier Device Package: 48-LQFP (7x7)
- detail: ARM® Cortex®-M4F STM32G4 Microcontroller IC 32-Bit 170MHz 128KB (128K x 8) FLASH 48-LQFP (7x7)
