دیتاشیت LPC2468FBD208,551
مشخصات دیتاشیت
| نام دیتاشیت | LPC2468 |
|---|---|
| حجم فایل | 496.568 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 85 |
دانلود دیتاشیت LPC2468 |
LPC2468 Datasheet |
|---|
مشخصات
- RoHS: true
- CPU Core: ARM其它系列
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- ADC (Bit): 10bit
- DAC (Bit): 10bit
- Datasheet: NXP Semicon LPC2468FBD208,551
- CPU Maximum Speed: 72MHz
- GPIO Ports Number: 160
- Direct Memory Access: Yes
- Universal Serial Bus: Yes
- Operating Voltage Range: 3V~3.6V
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: Yes
- Package: LQFP-208(28x28)
- Manufacturer: NXP Semicon
- Series: LPC2400
- Packaging: Tray
- Part Status: Discontinued at Digi-Key
- Core Processor: ARM7®
- Core Size: 16/32-Bit
- Speed: 72MHz
- Connectivity: CANbus, EBI/EMI, Ethernet, I²C, Microwire, Memory Card, SPI, SSI, SSP, UART/USART, USB OTG
- Peripherals: Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT
- Number of I/O: 160
- Program Memory Size: 512KB (512K x 8)
- Program Memory Type: FLASH
- EEPROM Size: -
- RAM Size: 98K x 8
- Voltage - Supply (Vcc/Vdd): 3V ~ 3.6V
- Data Converters: A/D 8x10b; D/A 1x10b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 208-LQFP
- Supplier Device Package: 208-LQFP (28x28)
- Base Part Number: LPC24
- detail: ARM7® LPC2400 Microcontroller IC 16/32-Bit 72MHz 512KB (512K x 8) FLASH 208-LQFP (28x28)
