دیتاشیت MK20DX128VFM5
مشخصات دیتاشیت
| نام دیتاشیت | K20_FM5 Datasheet |
|---|---|
| حجم فایل | 2084.729 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 58 |
دانلود دیتاشیت K20_FM5 Datasheet |
K20_FM5 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- EEPROM: -
- CPU Core: ARM Cortex-M4
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 16KB
- Watchdog: Yes
- ADC (Bit): 16bit
- DAC (Bit): -
- Datasheet: NXP Semicon MK20DX128VFM5
- PWM (Bit): -
- Real-Time Clock: -
- CPU Maximum Speed: 50MHz
- GPIO Ports Number: 20
- Low-Voltage Detect: Yes
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: DMA;Low-VoltageDetect;WDT
- Program Memory Type: FLASH
- Direct Memory Access: Yes
- Program Storage Size: 128KB
- Universal Serial Bus: Yes
- communication protocol: -
- Operating Voltage Range: 1.71V~3.6V
- Infrared Data Association: Yes
- Operating Temperature Range: -40°C~+105°C
- Secure Digital Input and Output: -
- Package: QFN-32-EP(5x5)
- Manufacturer: NXP Semicon
- Series: Kinetis K20
- Packaging: Tray
- Part Status: Active
- Core Processor: ARM® Cortex®-M4
- Core Size: 32-Bit
- Speed: 50MHz
- Connectivity: I²C, IrDA, SPI, UART/USART, USB, USB OTG
- Peripherals: DMA, I²S, LVD, POR, PWM, WDT
- Number of I/O: 20
- Program Memory Size: 128KB (128K x 8)
- EEPROM Size: 2K x 8
- Voltage - Supply (Vcc/Vdd): 1.71V ~ 3.6V
- Data Converters: A/D 6x16b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 105°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 32-VFQFN Exposed Pad
- Supplier Device Package: 32-QFN-EP (5x5)
- Base Part Number: MK20
- detail: ARM® Cortex®-M4 Kinetis K20 Microcontroller IC 32-Bit 50MHz 128KB (128K x 8) FLASH 32-QFN-EP (5x5)
