دیتاشیت STM8L151G4U6

مشخصات دیتاشیت

دانلود دیتاشیت STM8L15xx4, xx6 Datasheet	STM8L15xx4, xx6 Datasheet Datasheet

RoHS: true
EEPROM: -
CPU Core: STM8
Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
RAM Size: 2KB
Watchdog: Yes
ADC (Bit): 12bit
DAC (Bit): 12bit
Datasheet: STMicroelectronics STM8L151G4U6
PWM (Bit): -
Real-Time Clock: -
CPU Maximum Speed: 16MHz
GPIO Ports Number: 26
Low-Voltage Detect: Yes
CCP Capture/Compare: -
Internal Comparator: -
Internal Oscillator: Yes
Peripheral/Function: DMA;IrDA;PWM
Program Memory Type: FLASH
Direct Memory Access: Yes
Program Storage Size: 16KB
Universal Serial Bus: -
communication protocol: -
Operating Voltage Range: 1.8V~3.6V
Infrared Data Association: Yes
Operating Temperature Range: -40°C~+85°C
Secure Digital Input and Output: -
Package: UFQFPN-28(4x4)
Manufacturer: STMicroelectronics
Mfr: STMicroelectronics
Series: STM8L EnergyLite
Part Status: Active
Core Processor: STM8
Core Size: 8-Bit
Speed: 16MHz
Connectivity: I²C, IrDA, SPI, UART/USART
Peripherals: Brown-out Detect/Reset, DMA, IR, POR, PWM, WDT
Program Memory Size: 16KB (16K x 8)
EEPROM Size: 1K x 8
Voltage - Supply (Vcc/Vdd): 1.8V ~ 3.6V
Data Converters: A/D 18x12b; D/A 1x12b
Oscillator Type: Internal
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Package / Case: 28-UFQFN
Supplier Device Package: 28-UFQFPN (4x4)
Number of I/O: 26
Base Product Number: STM8L
