دیتاشیت STM8L151G6U6

STM8L15xx4, xx6 Datasheet

مشخصات دیتاشیت

نام دیتاشیت STM8L15xx4, xx6 Datasheet
حجم فایل 2002.102 کیلوبایت
نوع فایل pdf
تعداد صفحات 141

دانلود دیتاشیت STM8L15xx4, xx6 Datasheet

STM8L15xx4, xx6 Datasheet Datasheet

مشخصات

  • RoHS: true
  • CPU Core: STM8
  • Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
  • Watchdog: Yes
  • ADC (Bit): 12bit
  • DAC (Bit): 12bit
  • Datasheet: STMicroelectronics STM8L151G6U6
  • CPU Maximum Speed: 16MHz
  • GPIO Ports Number: 26
  • Low-Voltage Detect: Yes
  • Internal Oscillator: Yes
  • Direct Memory Access: Yes
  • Program Storage Size: 32KB
  • Operating Voltage Range: 1.8V~3.6V
  • Infrared Data Association: Yes
  • Operating Temperature Range: -40°C~+85°C
  • Package: UFQFPN-28(4x4)
  • Manufacturer: STMicroelectronics
  • Mfr: STMicroelectronics
  • Series: STM8L EnergyLite
  • Part Status: Active
  • Core Processor: STM8
  • Core Size: 8-Bit
  • Speed: 16MHz
  • Connectivity: I²C, IrDA, SPI, UART/USART
  • Peripherals: Brown-out Detect/Reset, DMA, IR, POR, PWM, WDT
  • Program Memory Size: 32KB (32K x 8)
  • Program Memory Type: FLASH
  • EEPROM Size: 1K x 8
  • RAM Size: 2K x 8
  • Voltage - Supply (Vcc/Vdd): 1.8V ~ 3.6V
  • Data Converters: A/D 18x12b; D/A 1x12b
  • Oscillator Type: Internal
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 28-UFQFN
  • Supplier Device Package: 28-UFQFPN (4x4)
  • Number of I/O: 26
  • Base Product Number: STM8L
