دیتاشیت LPC1768FBD100K
مشخصات دیتاشیت
| نام دیتاشیت | LPC1763-69 Datasheet |
|---|---|
| حجم فایل | 3195.625 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 93 |
دانلود دیتاشیت LPC1763-69 Datasheet |
LPC1763-69 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- EEPROM: -
- CPU Core: ARM Cortex-M3
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 64KB
- Watchdog: -
- ADC (Bit): 12bit
- DAC (Bit): 10bit
- Datasheet: NXP Semicon LPC1768FBD100K
- PWM (Bit): -
- Real-Time Clock: -
- CPU Maximum Speed: 100MHz
- GPIO Ports Number: 70
- Low-Voltage Detect: -
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: PWM;WDT
- Program Memory Type: FLASH
- Direct Memory Access: -
- Program Storage Size: 512KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 2.4V~3.6V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: LQFP-100(14x14)
- Manufacturer: NXP Semicon
- Series: LPC17xx
- Part Status: Active
- Core Processor: ARM® Cortex®-M3
- Core Size: 32-Bit
- Speed: 100MHz
- Connectivity: CANbus, Ethernet, I²C, IrDA, Microwire, SPI, SSI, UART/USART, USB OTG
- Peripherals: Brown-out Detect/Reset, DMA, I²S, Motor Control PWM, POR, PWM, WDT
- Number of I/O: 70
- Program Memory Size: 512KB (512K x 8)
- EEPROM Size: -
- Voltage - Supply (Vcc/Vdd): 2.4V ~ 3.6V
- Data Converters: A/D 8x12b; D/A 1x10b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 100-LQFP
- Supplier Device Package: 100-LQFP (14x14)
- Base Part Number: LPC17
- detail: ARM® Cortex®-M3 LPC17xx Microcontroller IC 32-Bit 100MHz 512KB (512K x 8) FLASH 100-LQFP (14x14)
