دیتاشیت TC1550TG-G

TC1550

مشخصات دیتاشیت

نام دیتاشیت TC1550
حجم فایل 425.281 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت TC1550

TC1550 Datasheet

مشخصات

  • RoHS: true
  • Type: 1PCSN-Channel&1PCSP-Channel
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Drain Source Voltage (Vdss): 500V
  • Input Capacitance (Ciss@Vds): 55pF@25V
  • Gate Threshold Voltage (Vgs(th)@Id): 4V@1mA
  • Drain Source On Resistance (RDS(on)@Vgs,Id): 60Ω@50mA,10V
  • Package: SO-8
  • Manufacturer: Microchip Tech
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • FET Type: N and P-Channel
  • FET Feature: Standard
  • Drain to Source Voltage (Vdss): 500V
  • Current - Continuous Drain (Id) @ 25°C: -
  • Rds On (Max) @ Id, Vgs: 60Ohm @ 50mA, 10V
  • Vgs(th) (Max) @ Id: 4V @ 1mA
  • Gate Charge (Qg) (Max) @ Vgs: -
  • Input Capacitance (Ciss) (Max) @ Vds: 55pF @ 25V
  • Power - Max: -
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 8-SOIC
  • detail: Mosfet Array N and P-Channel 500V Surface Mount 8-SOIC
