دیتاشیت FGD3245G2-F085

FG(B,D)3245G2_F085

مشخصات دیتاشیت

نام دیتاشیت FG(B,D)3245G2_F085
حجم فایل 1139.621 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت FG(B,D)3245G2_F085

FG(B,D)3245G2_F085 Datasheet

مشخصات

  • RoHS: true
  • Type: -
  • Category: Triode/MOS Tube/Transistor/IGBTs
  • Datasheet: onsemi FGD3245G2-F085
  • Operating Temperature: -40°C~+175°C@(Tj)
  • Collector Current (Ic): 23A
  • Power Dissipation (Pd): 150W
  • Turn?on Delay Time (Td(on)): 900ns
  • Input Capacitance (Cies@Vce): -
  • Turn?on Switching Loss (Eon): -
  • Total Gate Charge (Qg@Ic,Vge): 23nC
  • Turn?off Delay Time (Td(off)): 5.4us
  • Collector-Emitter Breakdown Voltage (Vces): 450V
  • Gate-Emitter Threshold Voltage (Vge(th)@Ic): 1.25V@4V,6A
  • Package: TO-252
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q101, EcoSPARK®
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • IGBT Type: -
  • Voltage - Collector Emitter Breakdown (Max): 450V
  • Current - Collector (Ic) (Max): 23A
  • Vce(on) (Max) @ Vge, Ic: 1.25V @ 4V, 6A
  • Power - Max: 150W
  • Switching Energy: -
  • Input Type: Logic
  • Gate Charge: 23nC
  • Td (on/off) @ 25°C: 900ns/5.4µs
  • Test Condition: -
  • Mounting Type: Surface Mount
  • Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Supplier Device Package: TO-252AA
  • Base Part Number: FGD3
  • detail: IGBT 450V 23A 150W Surface Mount TO-252AA
