دیتاشیت MIC4425YN
مشخصات دیتاشیت
| نام دیتاشیت | MIC4423, MIC4424, MIC4425 |
|---|---|
| حجم فایل | 221.239 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 13 |
دانلود دیتاشیت MIC4423, MIC4424, MIC4425 |
MIC4423, MIC4424, MIC4425 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Gate Drive ICs
- Datasheet: Microchip Tech MIC4425YN
- Fall Time: 32ns
- Load Type: MOSFET
- Rise Time: 28ns
- Supply Voltage: 4.5V~18V
- Number of Drivers: 2
- Driven Configuration: Low Side
- Operating Temperature: -40°C~+150°C@(Tj)
- Peak Output Current(sink): 3A
- Peak Output Current(source): 3A
- Package: PDIP-8
- Manufacturer: Microchip Tech
- Series: -
- Packaging: Tube
- Part Status: Active
- Channel Type: Independent
- Gate Type: N-Channel, P-Channel MOSFET
- Voltage - Supply: 4.5V ~ 18V
- Logic Voltage - VIL, VIH: 0.8V, 2.4V
- Current - Peak Output (Source, Sink): 3A, 3A
- Input Type: Inverting, Non-Inverting
- Rise / Fall Time (Typ): 28ns, 32ns
- Mounting Type: Through Hole
- Package / Case: 8-DIP (0.300", 7.62mm)
- Supplier Device Package: 8-PDIP
- Base Part Number: MIC4425
- detail: Low-Side Gate Driver IC Inverting, Non-Inverting 8-PDIP
