دیتاشیت TC7652CPA

TC7652

مشخصات دیتاشیت

نام دیتاشیت TC7652
حجم فایل 216.472 کیلوبایت
نوع فایل pdf
تعداد صفحات 18

دانلود دیتاشیت TC7652

TC7652 Datasheet

مشخصات

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Precision OpAmps
  • Datasheet: Microchip Tech TC7652CPA
  • Rail to Rail: -
  • Number of Circuits: 1
  • -3db Bandwidth(G=1): -
  • Operating Temperature: 0°C~+70°C
  • Current - Input Bias(Ib): 30pA
  • Gain Bandwidth Product(GBP): 400kHz
  • Voltage - Input Offset(Vos): 2mV
  • Package: PDIP-8
  • Manufacturer: Microchip Tech
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Amplifier Type: Zero-Drift
  • Output Type: -
  • Slew Rate: 1V/µs
  • Gain Bandwidth Product: 400kHz
  • Current - Input Bias: 30pA
  • Voltage - Input Offset: 2mV
  • Current - Supply: 1mA
  • Voltage - Supply, Single/Dual (±): 5V ~ 16V, ±2.5V ~ 8V
  • Mounting Type: Through Hole
  • Package / Case: 8-DIP (0.300", 7.62mm)
  • Supplier Device Package: 8-PDIP
  • Base Part Number: TC7652
  • detail: Zero-Drift Amplifier 1 Circuit 8-PDIP
