DN3545 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
DN3545
|
|
حجم فایل
|
1767.553
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
14
|
مشخصات فنی
-
Manufacturer:
Microchip Technology
-
Series:
-
-
Packaging:
Bulk
-
Part Status:
Active
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
450V
-
Current - Continuous Drain (Id) @ 25°C:
136mA
-
Drive Voltage (Max Rds On, Min Rds On):
0V
-
Rds On (Max) @ Id, Vgs:
20Ohm @ 150mA, 0V
-
Vgs(th) (Max) @ Id:
-
-
Vgs (Max):
±20V
-
Input Capacitance (Ciss) (Max) @ Vds:
360pF @ 25V
-
FET Feature:
Depletion Mode
-
Power Dissipation (Max):
740mW (Ta)
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Through Hole
-
Supplier Device Package:
TO-92 (TO-226)
-
Package / Case:
TO-226-3, TO-92-3 (TO-226AA)
-
detail:
N-Channel 450V 136mA 740mW (Ta) Through Hole TO-92 (TO-226)
