دیتاشیت TC1427CPA

TC142(6, 7, 8)

مشخصات دیتاشیت

نام دیتاشیت TC142(6, 7, 8)
حجم فایل 772.806 کیلوبایت
نوع فایل pdf
تعداد صفحات 16

دانلود دیتاشیت TC142(6, 7, 8)

TC142(6, 7, 8) Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/Gate Drive ICs
  • Datasheet: Microchip Tech TC1427CPA
  • Fall Time: 25ns
  • Load Type: MOSFET
  • Rise Time: 35ns
  • Supply Voltage: 4.5V~16V
  • Number of Drivers: 2
  • Driven Configuration: Low Side
  • Operating Temperature: 0°C~+70°C@(Ta)
  • Peak Output Current(sink): 1.2A
  • Peak Output Current(source): 1.2A
  • Package: PDIP-8
  • Manufacturer: Microchip Tech
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Channel Type: Independent
  • Gate Type: N-Channel, P-Channel MOSFET
  • Voltage - Supply: 4.5V ~ 16V
  • Logic Voltage - VIL, VIH: 0.8V, 3V
  • Current - Peak Output (Source, Sink): 1.2A, 1.2A
  • Input Type: Non-Inverting
  • Rise / Fall Time (Typ): 35ns, 25ns
  • Mounting Type: Through Hole
  • Package / Case: 8-DIP (0.300", 7.62mm)
  • Supplier Device Package: 8-PDIP
  • Base Part Number: TC1427
