دیتاشیت MPX5050DP

MPX5050, MPXV5050G Series

مشخصات دیتاشیت

نام دیتاشیت MPX5050, MPXV5050G Series
حجم فایل 462.945 کیلوبایت
نوع فایل pdf
تعداد صفحات 18

دانلود دیتاشیت MPX5050, MPXV5050G Series

MPX5050, MPXV5050G Series Datasheet

مشخصات

  • Manufacturer: NXP USA Inc.
  • Series: MPX5050
  • Part Status: Active
  • Applications: Board Mount
  • Pressure Type: Differential
  • Operating Pressure: 7.25PSI (50kPa)
  • Output Type: Analog Voltage
  • Output: 0.2 V ~ 4.7 V
  • Accuracy: ±2.5%
  • Voltage - Supply: 4.75V ~ 5.25V
  • Port Size: -
  • Port Style: No Port
  • Features: Temperature Compensated
  • Termination Style: PC Pin
  • Maximum Pressure: 29.01PSI (200kPa)
  • Operating Temperature: -40°C ~ 125°C
  • Package / Case: 6-SIP Module
  • Supplier Device Package: -
  • Base Part Number: MPX50
  • detail: Pressure Sensor 7.25PSI (50kPa) Differential 0.2 V ~ 4.7 V 6-SIP Module
