دیتاشیت MC9S08AC8CFGE
مشخصات دیتاشیت
| نام دیتاشیت | MC9S08AC(8,16), MC9S08AW(8,16) |
|---|---|
| حجم فایل | 6077.113 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 339 |
دانلود دیتاشیت MC9S08AC(8,16), MC9S08AW(8,16) |
MC9S08AC(8,16), MC9S08AW(8,16) Datasheet |
|---|
مشخصات
- Manufacturer: NXP USA Inc.
- Series: S08
- Packaging: Tray
- Part Status: Active
- Core Processor: S08
- Core Size: 8-Bit
- Speed: 40MHz
- Connectivity: I²C, SCI, SPI
- Peripherals: LVD, POR, PWM, WDT
- Number of I/O: 34
- Program Memory Size: 8KB (8K x 8)
- Program Memory Type: FLASH
- EEPROM Size: -
- RAM Size: 768 x 8
- Voltage - Supply (Vcc/Vdd): 2.7V ~ 5.5V
- Data Converters: A/D 8x10b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 44-LQFP
- Supplier Device Package: 44-LQFP (10x10)
- Base Part Number: MC9S0
- detail: S08 S08 Microcontroller IC 8-Bit 40MHz 8KB (8K x 8) FLASH 44-LQFP (10x10)
