دیتاشیت TPS61041DBVR
مشخصات دیتاشیت
| نام دیتاشیت |
TPS61040/41
|
| حجم فایل |
2232.485
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
36
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
boost converterType
-
Topology:
Boost
-
Datasheet:
Texas Instruments TPS61041DBVR
-
Input Voltage:
1.8V~6V
-
Output Voltage:
28V
-
Number of Outputs:
1
-
Switching Frequency:
1MHz
-
Output Current (Max):
215mA
-
Synchronous Rectification:
NO
-
Package:
SOT-23-5
-
Manufacturer:
Texas Instruments
-
Frequency:
1MHz
-
Dimming:
PWM
-
Internal Switch(s):
Yes
-
Voltage - Output:
28V
-
Base Part Number:
TPS610
-
Type:
DC DC Regulator
-
Package / Case:
SC-74A, SOT-753
-
Supplier Device Package:
SOT-23-5
-
Mounting Type:
Surface Mount
-
Part Status:
Active
-
Voltage - Supply (Max):
6V
-
Voltage - Supply (Min):
1.8V
-
Current - Output / Channel:
215mA (Switch)
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Applications:
Backlight
