دیتاشیت TPS73601DCQR
مشخصات دیتاشیت
| نام دیتاشیت |
TPS736xx
|
| حجم فایل |
1717.382
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
42
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments TPS73601DCQR
-
Output Type:
Adjustable
-
Output Current:
400mA
-
Output Voltage:
1.2V~5.5V
-
Dropout Voltage:
0.2V@(400mA)
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
5.5V
-
Operating Temperature:
-40°C~+125°C
-
Quiescent Current (Ground Current):
550uA
-
Package:
SOT-223-6
-
Manufacturer:
Texas Instruments
-
Control Features:
Enable
-
Base Part Number:
TPS736
-
Package / Case:
SOT-223-6
-
Current - Supply (Max):
1mA
-
Part Status:
Active
-
Current - Output:
400mA
-
PSRR:
58dB ~ 37dB (100Hz ~ 10kHz)
-
Series:
-
-
Voltage - Output (Min/Fixed):
1.2V
-
Mounting Type:
Surface Mount
-
Number of Regulators:
1
-
Current - Quiescent (Iq):
550µA
-
Output Configuration:
Positive
-
Voltage Dropout (Max):
0.2V @ 400mA
-
Supplier Device Package:
SOT-223-6
-
Protection Features:
Over Current, Over Temperature, Reverse Polarity
-
Voltage - Input (Max):
5.5V
-
Packaging:
Cut Tape (CT)
-
Voltage - Output (Max):
5.5V
-
detail:
Linear Voltage Regulator IC 1 Output 400mA SOT-223-6
