دیتاشیت MPXV2053DP

مشخصات دیتاشیت

دانلود دیتاشیت MPX2053, MPXV2053G Series	MPX2053, MPXV2053G Series Datasheet

RoHS: true
Category: Sensors/Pressure Sensors
Datasheet: NXP Semicon MPXV2053DP
Pressure range: 50Kpa
Operating Temperature: -40°C~+125°C
The Power Supply Voltage: 10V~16V
Package: SMD-8P
Manufacturer: NXP Semicon
Series: MPXV2053
Part Status: Active
Applications: Board Mount
Pressure Type: Differential
Operating Pressure: 7.25PSI (50kPa)
Output Type: Wheatstone Bridge
Output: 0 mV ~ 40 mV (10V)
Accuracy: -0.6% ~ 0.4%
Voltage - Supply: 10V ~ 16V
Port Size: Male - 0.13" (3.3mm) Tube, Dual
Port Style: Barbed
Features: Temperature Compensated
Termination Style: Gull Wing
Maximum Pressure: 29.01PSI (200kPa)
Package / Case: 8-BSOP (0.475", 12.06mm Width) Dual Ports, Same Side
Supplier Device Package: 8-SOP
Base Part Number: MPXV2
detail: Pressure Sensor 7.25PSI (50kPa) Differential Male - 0.13" (3.3mm) Tube, Dual 0 mV ~ 40 mV (10V) 8-BSOP (0.475", 12.06mm Width) Dual Ports, Same Side
