دیتاشیت MC9S12DG128BCFU
مشخصات دیتاشیت
| نام دیتاشیت | MC9S12DT128B Guide |
|---|---|
| حجم فایل | 2236.293 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 128 |
دانلود دیتاشیت MC9S12DT128B Guide |
MC9S12DT128B Guide Datasheet |
|---|
مشخصات
- Manufacturer: NXP USA Inc.
- Series: HCS12
- Packaging: Tray
- Part Status: Obsolete
- Core Processor: HCS12
- Core Size: 16-Bit
- Speed: 25MHz
- Connectivity: CANbus, I²C, SCI, SPI
- Peripherals: PWM, WDT
- Number of I/O: 59
- Program Memory Size: 128KB (128K x 8)
- Program Memory Type: FLASH
- EEPROM Size: 2K x 8
- RAM Size: 8K x 8
- Voltage - Supply (Vcc/Vdd): 2.35V ~ 5.25V
- Data Converters: A/D 16x10b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 80-QFP
- Supplier Device Package: 80-QFP (14x14)
- Base Part Number: MC9S1
- detail: HCS12 HCS12 Microcontroller IC 16-Bit 25MHz 128KB (128K x 8) FLASH 80-QFP (14x14)
