- دیتاشیت MAX913CSA
MAX913CSA دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MAX913CSA |
|---|---|
| حجم فایل | 98.571 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 11 |
دانلود دیتاشیت MAX913CSA |
دانلود دیتاشیت |
|---|
سایر مستندات
Part Numbering System 7 pages
MAX912,913 11 pages
مشخصات فنی
- RoHS: true
- Category: Operational Amplifier/Comparator/Comparators
- Datasheet: Analog Devices Inc./Maxim Integrated MAX913CSA
- Supply Current: 10mA
- Number of Elements: 1
- Operating Temperature: 0°C~+70°C
- Propagation Delay Time: 14ns
- Package: SOP-8
- Manufacturer: Analog Devices Inc./Maxim Integrated
- Voltage - Supply, Single/Dual (±): 5V ~ 10V
- Voltage - Input Offset (Max): 2mV @ ±5V
- Hysteresis: -
- Output Type: Complementary, TTL
- Supplier Device Package: 8-SOIC
- CMRR, PSRR (Typ): 110dB CMRR, 100dB PSRR
- Propagation Delay (Max): 14ns
- Part Status: Obsolete
- Type: with Latch
- Series: -
- Current - Quiescent (Max): 10mA
- Base Part Number: MAX913
- Current - Output (Typ): 20mA
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Packaging: Tube
- Mounting Type: Surface Mount
- Current - Input Bias (Max): 5µA @ ±5V
- detail: Comparator with Latch Complementary, TTL 8-SOIC
