APT8020(B2,L)LL دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
APT8020(B2,L)LL
|
|
حجم فایل
|
1659.48
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
5
|
مشخصات فنی
-
Manufacturer:
Microchip Technology
-
Series:
POWER MOS 7®
-
Packaging:
Tube
-
Part Status:
Active
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
800V
-
Current - Continuous Drain (Id) @ 25°C:
38A (Tc)
-
Rds On (Max) @ Id, Vgs:
200mOhm @ 19A, 10V
-
Vgs(th) (Max) @ Id:
5V @ 2.5mA
-
Gate Charge (Qg) (Max) @ Vgs:
195nC @ 10V
-
Input Capacitance (Ciss) (Max) @ Vds:
5200pF @ 25V
-
FET Feature:
-
-
Mounting Type:
Through Hole
-
Supplier Device Package:
TO-264 [L]
-
Package / Case:
TO-264-3, TO-264AA
-
detail:
N-Channel 800V 38A (Tc) Through Hole TO-264 [L]
