AT45DB161E-SHD-T Datasheet
Datasheet specifications
| Datasheet's name | AT45DB161E-SHD-T |
|---|---|
| File size | 73.089 KB |
| File type | |
| Number of pages | 73 |
Download Datasheet AT45DB161E-SHD-T |
Download Datasheet |
|---|
Other documentations
AT45DB161E 70 pages
Technical specifications
- RoHS: true
- Category: Memory/NOR FLASH
- Datasheet: Dialog Semiconductor/Adesto Adesto Technologies AT45DB161E-SHD-T
- Package: SOP-8-208mil
- Manufacturer: Dialog Semiconductor/Adesto Adesto Technologies
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Obsolete
- Memory Type: Non-Volatile
- Memory Format: FLASH
- Technology: FLASH
- Memory Size: 16Mb (528 Bytes x 4096 pages)
- Memory Interface: SPI
- Clock Frequency: 85MHz
- Write Cycle Time - Word, Page: 8µs, 6ms
- Voltage - Supply: 2.5V ~ 3.6V
- Operating Temperature: -40°C ~ 85°C (TC)
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.209", 5.30mm Width)
- Supplier Device Package: 8-SOIC
- Base Part Number: AT45DB161
- detail: FLASH Memory IC 16Mb (528 Bytes x 4096 pages) SPI 85MHz 8-SOIC
