دیتاشیت C8051F550-IM

C8051F55x, 56x, 57x Datasheet

مشخصات دیتاشیت

نام دیتاشیت C8051F55x, 56x, 57x Datasheet
حجم فایل 9733.235 کیلوبایت
نوع فایل pdf
تعداد صفحات 308

دانلود دیتاشیت C8051F55x, 56x, 57x Datasheet

C8051F55x, 56x, 57x Datasheet Datasheet

مشخصات

  • RoHS: true
  • CPU Core: 51Series
  • Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
  • Watchdog: Yes
  • ADC (Bit): 12bit
  • Datasheet: SILICON LABS C8051F550-IM
  • CPU Maximum Speed: 50MHz
  • GPIO Ports Number: 18
  • Low-Voltage Detect: Yes
  • Internal Oscillator: Yes
  • Program Storage Size: 32KB
  • Operating Voltage Range: 1.8V~5.25V
  • Operating Temperature Range: -40°C~+125°C
  • Package: QFN-24-EP(4x4)
  • Manufacturer: SILICON LABS
  • Oscillator Type: Internal
  • Packaging: Tube
  • Core Processor: 8051
  • Speed: 50MHz
  • Operating Temperature: -40°C ~ 125°C (TA)
  • EEPROM Size: -
  • Part Status: Active
  • Peripherals: POR, PWM, Temp Sensor, WDT
  • Package / Case: 24-WFQFN Exposed Pad
  • Connectivity: SMBus (2-Wire/I²C), CANbus, LINbus, SPI, UART/USART
  • Number of I/O: 18
  • Core Size: 8-Bit
  • Series: C8051F55x
  • Program Memory Size: 32KB (32K x 8)
  • Program Memory Type: FLASH
  • Supplier Device Package: 24-QFN (4x4)
  • Mounting Type: Surface Mount
  • RAM Size: 2.25K x 8
  • Data Converters: A/D 18x12b
  • Voltage - Supply (Vcc/Vdd): 1.8V ~ 5.25V
  • Base Part Number: C8051F55
  • detail: 8051 C8051F55x Microcontroller IC 8-Bit 50MHz 32KB (32K x 8) FLASH 24-QFN (4x4)
