دیتاشیت ESD8104MUTAG
مشخصات دیتاشیت
| نام دیتاشیت |
ESD8104
|
| حجم فایل |
607.996
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
13
|
مشخصات
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Type:
Zener
-
Unidirectional Channels:
4
-
Voltage - Reverse Standoff (Typ):
3.3V (Max)
-
Voltage - Breakdown (Min):
4V
-
Voltage - Clamping (Max) @ Ipp:
11.4V (Typ)
-
Current - Peak Pulse (10/1000µs):
16A (100ns)
-
Power - Peak Pulse:
-
-
Power Line Protection:
No
-
Applications:
HDMI, USB
-
Capacitance @ Frequency:
0.3pF @ 1MHz
-
Operating Temperature:
-55°C ~ 125°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
10-UFDFN
-
Supplier Device Package:
10-UDFN (2.5x1)
-
Base Part Number:
ESD81
-
detail:
11.4V (Typ) Clamp 16A (100ns) Ipp Tvs Diode Surface Mount 10-UDFN (2.5x1)
