دیتاشیت MUR460RLG
مشخصات دیتاشیت
| نام دیتاشیت | MUR405(10,15,20,40,60) |
|---|---|
| حجم فایل | 115.761 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 8 |
دانلود دیتاشیت MUR405(10,15,20,40,60) |
MUR405(10,15,20,40,60) Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Diodes/Diodes - Fast Recovery Rectifiers
- Datasheet: onsemi MUR460RLG
- Diode Configuration: Single
- Reverse Voltage (Vr): 600V
- Operating Temperature: -65°C~+175°C@(Tj)
- Forward Voltage (Vf@If): 1.28V@4A
- Reverse Leakage Current: 10uA@600V
- Reverse Recovery Time (trr): 75ns
- Average Rectified Current (Io): 4A
- Package: DO-27
- Manufacturer: onsemi
- Series: SWITCHMODE™
- Packaging: Cut Tape (CT)
- Part Status: Obsolete
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 600V
- Current - Average Rectified (Io): 4A
- Voltage - Forward (Vf) (Max) @ If: 1.28V @ 4A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 10µA @ 600V
- Capacitance @ Vr, F: -
- Mounting Type: Through Hole
- Package / Case: DO-201AA, DO-27, Axial
- Supplier Device Package: DO-201AD
- Operating Temperature - Junction: -65°C ~ 175°C
- Base Part Number: MUR46
- detail: Diode Standard 600V 4A Through Hole DO-201AD
