دیتاشیت NLAS4684MR2G
مشخصات دیتاشیت
| نام دیتاشیت |
NLAS4684
|
| حجم فایل |
177.742
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
14
|
مشخصات
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
-
Datasheet:
onsemi NLAS4684MR2G
-
Turn-on time:
30ns
-
Turn-off time:
30ns
-
Supply Voltage:
1.8V~5.5V
-
Switch Circuit:
SPDT(SPDT)
-
Number of Channels:
2
-
On-State Resistance (Max):
800mΩ
-
Package:
Micro-10
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
Multiplexer/Demultiplexer Circuit:
2:1
-
Number of Circuits:
2
-
Channel-to-Channel Matching (ΔRon):
60mOhm
-
Voltage - Supply, Single (V+):
1.8V ~ 5.5V
-
Voltage - Supply, Dual (V±):
-
-
Switch Time (Ton, Toff) (Max):
30ns, 30ns
-
-3db Bandwidth:
9.5MHz
-
Charge Injection:
15pC
-
Channel Capacitance (CS(off), CD(off)):
102pF, 104pF
-
Current - Leakage (IS(off)) (Max):
1µA
-
Crosstalk:
-83dB @ 100kHz
-
Operating Temperature:
-55°C ~ 125°C (TA)
-
Mounting Type:
Surface Mount
-
Package / Case:
10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
-
Supplier Device Package:
10-Micro
-
Base Part Number:
NLAS4
-
detail:
2 Circuit IC Switch 2:1 800mOhm 10-Micro
