دیتاشیت MMBZ33VALT1G
مشخصات دیتاشیت
| نام دیتاشیت | MMBZ/SZMMBZyyyALT1 Series |
|---|---|
| حجم فایل | 146.186 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 8 |
دانلود دیتاشیت MMBZ/SZMMBZyyyALT1 Series |
MMBZ/SZMMBZyyyALT1 Series Datasheet |
|---|
مشخصات
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
- Datasheet: TECH PUBLIC MMBZ33VALT1G
- Package: SOT-23
- Manufacturer: TECH PUBLIC
- Clamping Voltage@Ipp: 46V
- Operating Temperature: -55°C~+150°C@(Tj)
- Breakdown Voltage (VBR): 31.35V
- Peak Pulse Power(Ppp)@8/20us: 40W
- Junction Capacitance(Cj)@1MHz: -
- Reverse Stand-Off Voltage (Vrwm): 26V
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: Zener
- Unidirectional Channels: 2
- Voltage - Reverse Standoff (Typ): 26V
- Voltage - Breakdown (Min): 31.35V
- Voltage - Clamping (Max) @ Ipp: 46V
- Current - Peak Pulse (10/1000µs): 870mA
- Power - Peak Pulse: 40W
- Power Line Protection: No
- Applications: General Purpose
- Capacitance @ Frequency: -
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Supplier Device Package: SOT-23-3 (TO-236)
- Base Part Number: MMBZ33
- detail: 46V Clamp 870mA Ipp Tvs Diode Surface Mount SOT-23-3 (TO-236)
