دیتاشیت BAV23S

BAV23S

مشخصات دیتاشیت

نام دیتاشیت BAV23S
حجم فایل 328.123 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت BAV23S

BAV23S Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Diodes - General Purpose
  • Datasheet: onsemi BAV23S
  • Diode Configuration: Dual
  • Reverse Voltage (Vr): 200V
  • Forward Voltage (Vf@If): 1.25V@200mA
  • Reverse Leakage Current: 100nA@250V
  • Average Rectified Current (Io): 250mA
  • Package: SOT-23(TO-236)
  • Manufacturer: onsemi
  • Power Dissipation: 350mW
  • Operating Temperature: +150°C@(Tj)
  • Reverse Recovery Time (trr): 50ns
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 250V
  • Current - Average Rectified (Io) (per Diode): 200mA
  • Voltage - Forward (Vf) (Max) @ If: 1.25V @ 200mA
  • Speed: Small Signal =< 200mA (Io), Any Speed
  • Current - Reverse Leakage @ Vr: 100nA @ 250V
  • Operating Temperature - Junction: 150°C (Max)
  • Mounting Type: Surface Mount
  • Package / Case: TO-236-3, SC-59, SOT-23-3
  • Supplier Device Package: SOT-23-3 (TO-236)
  • Base Part Number: BAV23
