دیتاشیت BCV27
مشخصات دیتاشیت
| نام دیتاشیت |
BCV27
|
| حجم فایل |
498.789
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
5
|
مشخصات
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/Darlington Transistors
-
Datasheet:
onsemi BCV27
-
Transistor Type:
NPN
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Collector Current (Ic):
1.2A
-
Power Dissipation (Pd):
350mW
-
Transition frequency (fT):
220MHz
-
DC current gain (hFE@Vce,Ic):
20000@5V,100mA
-
Collector-emitter voltage (Vceo):
30V
-
Collector cut-off current (Icbo@Vcb):
100nA
-
Collector-emitter saturation voltage (VCE(sat)@Ic,Ib):
1V@100mA,100uA
-
Package:
SOT-23(TO-236)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Current - Collector (Ic) (Max):
1.2A
-
Voltage - Collector Emitter Breakdown (Max):
30V
-
Vce Saturation (Max) @ Ib, Ic:
1V @ 100µA, 100mA
-
Current - Collector Cutoff (Max):
100nA (ICBO)
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
20000 @ 100mA, 5V
-
Power - Max:
350mW
-
Frequency - Transition:
220MHz
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-236-3, SC-59, SOT-23-3
-
Supplier Device Package:
SOT-23-3
-
Base Part Number:
BCV27
-
detail:
Bipolar (BJT) Transistor NPN - Darlington 30V 1.2A 220MHz 350mW Surface Mount SOT-23-3
