NL27WZ08USG دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NL27WZ08USG
|
|
حجم فایل
|
61.287
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
13
|
مشخصات فنی
-
RoHS:
true
-
Series:
27WZ
-
Category:
Logic ICs/Gates
-
Datasheet:
onsemi NL27WZ08USG
-
Sink Current:
32mA
-
Source Current:
32mA
-
Supply Voltage:
1.65V~5.5V
-
Logic Gate Type:
And
-
Number of Channels:
2
-
Operating Temperature:
-55°C~+125°C
-
Propagation Delay Time:
3.7ns@5V,50pF
-
Quiescent Current (Max):
1uA
-
Package:
US-8
-
Manufacturer:
onsemi
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Logic Type:
AND Gate
-
Number of Circuits:
2
-
Number of Inputs:
2
-
Features:
-
-
Voltage - Supply:
1.65V ~ 5.5V
-
Current - Quiescent (Max):
1µA
-
Current - Output High, Low:
32mA, 32mA
-
Logic Level - Low:
-
-
Logic Level - High:
-
-
Max Propagation Delay @ V, Max CL:
3.7ns @ 5V, 50pF
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
US8
-
Package / Case:
8-VFSOP (0.091", 2.30mm Width)
-
Base Part Number:
NL27W
-
detail:
AND Gate IC 2 Channel US8
