دیتاشیت MC74VHC1G04DTT1G
مشخصات دیتاشیت
| نام دیتاشیت |
MC74VHC1G04
|
| حجم فایل |
205.477
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
15
|
مشخصات
-
RoHS:
true
-
Series:
74VHC
-
Category:
Logic ICs/Inverters
-
Datasheet:
onsemi MC74VHC1G04DTT1G
-
Input Type:
-
-
Sink Current:
8mA
-
Source Current:
8mA
-
Number of Circuits:
1
-
Supply Current (Max):
1uA
-
Low level range (VIL):
0.5V~1.65V
-
Max Propagation Delay:
7.5ns@5V,50pF
-
High level range (VIH):
1.5V~3.85V
-
Supply Voltage(Single):
2V~5.5V
-
Package:
TSOP-5-1.5mm
-
Manufacturer:
onsemi
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
Logic Type:
Inverter
-
Number of Inputs:
1
-
Features:
-
-
Voltage - Supply:
2V ~ 5.5V
-
Current - Quiescent (Max):
1µA
-
Current - Output High, Low:
8mA, 8mA
-
Logic Level - Low:
0.5V ~ 1.65V
-
Logic Level - High:
1.5V ~ 3.85V
-
Max Propagation Delay @ V, Max CL:
7.5ns @ 5V, 50pF
-
Operating Temperature:
-55°C ~ 125°C
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
5-TSOP
-
Package / Case:
SOT-23-5 Thin, TSOT-23-5
-
Base Part Number:
MC74VHC1G04
-
detail:
Inverter IC 1 Channel 5-TSOP
