دیتاشیت MMBF4391LT1G
مشخصات دیتاشیت
| نام دیتاشیت |
MMBF4391LT1G
|
| حجم فایل |
137.882
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
6
|
مشخصات
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/JFETs
-
FET Type:
N-Channel
-
Datasheet:
onsemi MMBF4391LT1G
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Input Capacitance (Ciss@Vds):
14pF@15V
-
Total Device Dissipation (Pd):
225mW
-
Drain Current (Idss@Vds,Vgs=0):
50mA@15V
-
Gate-Source Breakdown Voltage (V(BR)GSS):
30V
-
Gate-Source Cutoff Voltage (VGS(off)@ID):
4V@10nA
-
Static Drain-Source On Resistance (RDS(on)):
30Ω
-
Package:
SOT-23(TO-236)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
Voltage - Breakdown (V(BR)GSS):
30V
-
Current - Drain (Idss) @ Vds (Vgs=0):
50mA @ 20V
-
Voltage - Cutoff (VGS off) @ Id:
4V @ 1nA
-
Input Capacitance (Ciss) (Max) @ Vds:
14pF @ 20V
-
Resistance - RDS(On):
30 Ohms
-
Power - Max:
350mW
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-236-3, SC-59, SOT-23-3
-
Supplier Device Package:
SOT-23-3
-
Base Part Number:
MMBF43
-
detail:
JFET N-Channel 30V 350mW Surface Mount SOT-23-3
