دیتاشیت ES3A
مشخصات دیتاشیت
| نام دیتاشیت |
ES3A-J
|
| حجم فایل |
312.144
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
6
|
مشخصات
-
RoHS:
true
-
Category:
Diodes/Diodes - Fast Recovery Rectifiers
-
Datasheet:
onsemi ES3A
-
Reverse Voltage (Vr):
50V
-
Operating Temperature:
-50°C~+150°C@(Tj)
-
Forward Voltage (Vf@If):
950mV@3A
-
Reverse Leakage Current:
10uA@50V
-
Reverse Recovery Time (trr):
20ns
-
Average Rectified Current (Io):
3A
-
Package:
DO-214AB
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Diode Type:
Standard
-
Voltage - DC Reverse (Vr) (Max):
50V
-
Current - Average Rectified (Io):
3A
-
Voltage - Forward (Vf) (Max) @ If:
950mV @ 3A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Current - Reverse Leakage @ Vr:
10µA @ 50V
-
Capacitance @ Vr, F:
45pF @ 4V, 1MHz
-
Mounting Type:
Surface Mount
-
Package / Case:
DO-214AB, SMC
-
Supplier Device Package:
SMC (DO-214AB)
-
Operating Temperature - Junction:
-50°C ~ 150°C
-
Base Part Number:
ES3
