SMS05T1G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
SMS05T1G
|
|
حجم فایل
|
95.017
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
5
|
مشخصات فنی
-
RoHS:
true
-
Category:
TVS/Fuse/Board Level Protection/ESD Protection Devices
-
Datasheet:
onsemi SMS05T1G
-
Number of Lines:
4
-
Clamping Voltage@Ipp:
15.5V
-
Breakdown Voltage (VBR):
6V
-
Package:
SC-74
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
Type:
Zener
-
Unidirectional Channels:
4
-
Voltage - Reverse Standoff (Typ):
5V
-
Voltage - Breakdown (Min):
6V
-
Voltage - Clamping (Max) @ Ipp:
15.5V
-
Current - Peak Pulse (10/1000µs):
23A (8/20µs)
-
Power - Peak Pulse:
350W
-
Power Line Protection:
No
-
Applications:
General Purpose
-
Capacitance @ Frequency:
250pF @ 1MHz
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
SC-74, SOT-457
-
Supplier Device Package:
SC-74
-
Base Part Number:
SMS05
-
detail:
15.5V Clamp 23A (8/20µs) Ipp Tvs Diode Surface Mount SC-74
