RHRG75120 Datasheet
Datasheet specifications
| Datasheet's name | RHRG75120 |
|---|---|
| File size | 350.957 KB |
| File type | |
| Number of pages | 4 |
Download Datasheet RHRG75120 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- RoHS: true
- Category: Diodes/Diodes - Fast Recovery Rectifiers
- Datasheet: onsemi RHRG75120
- Diode Configuration: Single
- Reverse Voltage (Vr): 1.2kV
- Operating Temperature: -65°C~+175°C@(Tj)
- Forward Voltage (Vf@If): 3.2V@75A
- Reverse Leakage Current: 250uA@1.2kV
- Reverse Recovery Time (trr): 100ns
- Average Rectified Current (Io): 75A
- Package: TO-247-2
- Manufacturer: onsemi
- Series: -
- Packaging: Tube
- Part Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 1200V
- Current - Average Rectified (Io): 75A
- Voltage - Forward (Vf) (Max) @ If: 3.2V @ 75A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 250µA @ 1200V
- Capacitance @ Vr, F: -
- Mounting Type: Through Hole
- Package / Case: TO-247-2
- Supplier Device Package: TO-247-2
- Operating Temperature - Junction: -65°C ~ 175°C
- Base Part Number: RHRG75
- detail: Diode Standard 1200V 75A Through Hole TO-247-2
