دیتاشیت NCP702SN30T1G
مشخصات دیتاشیت
| نام دیتاشیت |
NCP702
|
| حجم فایل |
1854.413
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
20
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
onsemi NCP702SN30T1G
-
Package:
TSOP-5-1.5mm
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Output Type:
Fixed
-
Number of Regulators:
1
-
Voltage - Input (Max):
5.5V
-
Voltage - Output (Min/Fixed):
3V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
-
-
Current - Output:
200mA
-
Current - Quiescent (Iq):
16µA
-
PSRR:
-
-
Control Features:
Enable
-
Protection Features:
Over Current, Over Temperature, Soft Start, Under Voltage Lockout (UVLO)
-
Operating Temperature:
-40°C ~ 125°C
-
Mounting Type:
Surface Mount
-
Package / Case:
SOT-23-5 Thin, TSOT-23-5
-
Supplier Device Package:
5-TSOP
-
Base Part Number:
NCP702
