MMBD7000 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
MMBD7000
|
|
حجم فایل
|
70.74
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
4
|
مشخصات فنی
-
RoHS:
true
-
Category:
Diodes/Switching Diode
-
Datasheet:
ST(Semtech) MMBD7000
-
Power Dissipation:
350mW
-
Diode Configuration:
Dual
-
Reverse Voltage (Vr):
100V
-
Operating Temperature:
-65°C~+150°C@(Tj)
-
Forward Voltage (Vf@If):
1.25V@150mA
-
Reverse Leakage Current:
1uA@50V
-
Reverse Recovery Time (trr):
4ns
-
Average Rectified Current (Io):
0.2A
-
Package:
SOT-23(SOT-236)
-
Manufacturer:
ST(Semtech)
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Last Time Buy
-
Diode Type:
Standard
-
Voltage - DC Reverse (Vr) (Max):
100V
-
Current - Average Rectified (Io) (per Diode):
200mA
-
Voltage - Forward (Vf) (Max) @ If:
1.1V @ 100mA
-
Speed:
Small Signal =< 200mA (Io), Any Speed
-
Current - Reverse Leakage @ Vr:
500nA @ 100V
-
Operating Temperature - Junction:
150°C (Max)
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-236-3, SC-59, SOT-23-3
-
Supplier Device Package:
SOT-23-3
-
Base Part Number:
MMBD70
