- دیتاشیت DTC123EM3T5G
DTC123EM3T5G دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | DTC123EM3T5G |
|---|---|
| حجم فایل | 89.245 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 12 |
دانلود دیتاشیت DTC123EM3T5G |
دانلود دیتاشیت |
|---|
سایر مستندات
MUN(2,5)231, MMUN2231L, DC123Exx 11 pages
مشخصات فنی
- RoHS: true
- Category: Triode/MOS Tube/Transistor/Digital Transistors
- Datasheet: onsemi DTC123EM3T5G
- Transistor Type: 1 NPN - Pre Biased
- Collector Current (Ic): 100mA
- Power Dissipation (Pd): 260mW
- DC Current Gain (hFE@Ic,Vce): 8@5mA,10V
- Collector Cut-Off Current (Icbo): 500nA
- Collector-Emitter Breakdown Voltage (Vceo): 50V
- Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib): 250mV@10mA,5mA
- Package: SOT-723
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Current - Collector (Ic) (Max): 100mA
- Voltage - Collector Emitter Breakdown (Max): 50V
- Resistor - Base (R1): 2.2 kOhms
- Resistor - Emitter Base (R2): 2.2 kOhms
- DC Current Gain (hFE) (Min) @ Ic, Vce: 8 @ 5mA, 10V
- Vce Saturation (Max) @ Ib, Ic: 250mV @ 5mA, 10mA
- Current - Collector Cutoff (Max): 500nA
- Power - Max: 260mW
- Mounting Type: Surface Mount
- Package / Case: SOT-723
- Supplier Device Package: SOT-723
- Base Part Number: DTC123
