دیتاشیت NCP5007SNT1G

NCP5007

مشخصات دیتاشیت

نام دیتاشیت NCP5007
حجم فایل 152.34 کیلوبایت
نوع فایل pdf
تعداد صفحات 21

دانلود دیتاشیت NCP5007

NCP5007 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Obsolete
  • Type: DC DC Regulator
  • Topology: Step-Up (Boost)
  • Internal Switch(s): Yes
  • Number of Outputs: 1
  • Voltage - Supply (Min): 2.7V
  • Voltage - Supply (Max): 5.5V
  • Voltage - Output: 24.5V
  • Current - Output / Channel: 50mA
  • Frequency: -
  • Dimming: PWM
  • Applications: Backlight
  • Operating Temperature: -25°C ~ 85°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: SOT-23-5 Thin, TSOT-23-5
  • Supplier Device Package: 5-TSOP
  • Base Part Number: NCP5007
  • detail: LED Driver IC 1 Output DC DC Regulator Step-Up (Boost) PWM Dimming 50mA 5-TSOP
