دیتاشیت SI4542DY
مشخصات دیتاشیت
| نام دیتاشیت |
SI4542DY
|
| حجم فایل |
162.145
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
4
|
مشخصات
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
onsemi SI4542DY
-
Package:
SOP-8
-
Manufacturer:
onsemi
-
Series:
PowerTrench®
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
FET Type:
N and P-Channel
-
FET Feature:
Standard
-
Drain to Source Voltage (Vdss):
30V
-
Current - Continuous Drain (Id) @ 25°C:
6A
-
Rds On (Max) @ Id, Vgs:
28mOhm @ 6A, 10V
-
Vgs(th) (Max) @ Id:
3V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
13nC @ 5V
-
Input Capacitance (Ciss) (Max) @ Vds:
830pF @ 15V
-
Power - Max:
1W
-
Operating Temperature:
-55°C ~ 175°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Supplier Device Package:
8-SOIC
-
Base Part Number:
SI454
-
detail:
Mosfet Array N and P-Channel 30V 6A 1W Surface Mount 8-SOIC
