دیتاشیت NSR0320MW2T1G

NSR0320MW2T1

مشخصات دیتاشیت

نام دیتاشیت NSR0320MW2T1
حجم فایل 164.262 کیلوبایت
نوع فایل pdf
تعداد صفحات 4

دانلود دیتاشیت NSR0320MW2T1

NSR0320MW2T1 Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Schottky Barrier Diodes (SBD)
  • Datasheet: onsemi NSR0320MW2T1G
  • Reverse Voltage (Vr): 20V
  • Forward Voltage (Vf@If): 500mV@900mA
  • Reverse Leakage Current (Ir): 50uA@15V
  • Average Rectified Current (Io): 1A
  • Package: SOD-323
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 20V
  • Current - Average Rectified (Io): 1A (DC)
  • Voltage - Forward (Vf) (Max) @ If: 500mV @ 900mA
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 50µA @ 15V
  • Capacitance @ Vr, F: 29pF @ 5V, 1MHz
  • Mounting Type: Surface Mount
  • Package / Case: SC-76, SOD-323
  • Supplier Device Package: SOD-323
  • Operating Temperature - Junction: -55°C ~ 125°C
  • Base Part Number: NSR032
  • detail: Diode Schottky 20V 1A (DC) Surface Mount SOD-323
