دیتاشیت 74ACT00SC
مشخصات دیتاشیت
| نام دیتاشیت | 74AC00, 74ACT00 |
|---|---|
| حجم فایل | 526.227 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 6 |
دانلود دیتاشیت 74AC00, 74ACT00 |
74AC00, 74ACT00 Datasheet |
|---|
مشخصات
- Manufacturer: ON Semiconductor
- Series: 74ACT
- Packaging: Tube
- Part Status: Active
- Logic Type: NAND Gate
- Number of Circuits: 4
- Number of Inputs: 2
- Features: -
- Voltage - Supply: 4.5V ~ 5.5V
- Current - Quiescent (Max): 2µA
- Current - Output High, Low: 24mA, 24mA
- Logic Level - Low: 0.8V
- Logic Level - High: 2V
- Max Propagation Delay @ V, Max CL: 9ns @ 5V, 50pF
- Operating Temperature: -40°C ~ 85°C
- Mounting Type: Surface Mount
- Supplier Device Package: 14-SOIC
- Package / Case: 14-SOIC (0.154", 3.90mm Width)
- Base Part Number: 74ACT00
- detail: NAND Gate IC 4 Channel 14-SOIC
