دیتاشیت 2N4124

2N4124

مشخصات دیتاشیت

نام دیتاشیت 2N4124
حجم فایل 124.201 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

دانلود دیتاشیت 2N4124

2N4124 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Bulk
  • Part Status: Obsolete
  • Transistor Type: NPN
  • Current - Collector (Ic) (Max): 200mA
  • Voltage - Collector Emitter Breakdown (Max): 25V
  • Vce Saturation (Max) @ Ib, Ic: 300mV @ 5mA, 50mA
  • Current - Collector Cutoff (Max): 50nA (ICBO)
  • DC Current Gain (hFE) (Min) @ Ic, Vce: 120 @ 2mA, 1V
  • Power - Max: 625mW
  • Frequency - Transition: 300MHz
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Through Hole
  • Package / Case: TO-226-3, TO-92-3 (TO-226AA)
  • Supplier Device Package: TO-92-3
  • Base Part Number: 2N4124
