دیتاشیت MPSW01A
مشخصات دیتاشیت
| نام دیتاشیت |
MPSW01(A)
|
| حجم فایل |
98.137
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
4
|
مشخصات
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Bulk
-
Part Status:
Obsolete
-
Transistor Type:
NPN
-
Current - Collector (Ic) (Max):
1A
-
Voltage - Collector Emitter Breakdown (Max):
40V
-
Vce Saturation (Max) @ Ib, Ic:
500mV @ 100mA, 1A
-
Current - Collector Cutoff (Max):
100nA (ICBO)
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
60 @ 100mA, 1V
-
Power - Max:
1W
-
Frequency - Transition:
50MHz
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Through Hole
-
Package / Case:
TO-226-3, TO-92-3 Long Body
-
Supplier Device Package:
TO-92 (TO-226)
-
Base Part Number:
MPSW01
-
detail:
Bipolar (BJT) Transistor NPN 40V 1A 50MHz 1W Through Hole TO-92 (TO-226)
