دیتاشیت BU806
مشخصات دیتاشیت
| نام دیتاشیت | TO220B03 Pkg Drawing |
|---|---|
| حجم فایل | 99.003 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 1 |
دانلود دیتاشیت TO220B03 Pkg Drawing |
TO220B03 Pkg Drawing Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
- Package: TO-220C
- Manufacturer: SPTECH
- Series: -
- Packaging: Bulk
- Part Status: Obsolete
- Transistor Type: NPN - Darlington
- Current - Collector (Ic) (Max): 8A
- Voltage - Collector Emitter Breakdown (Max): 200V
- Vce Saturation (Max) @ Ib, Ic: 1.5V @ 50mA, 5A
- Current - Collector Cutoff (Max): 100µA
- DC Current Gain (hFE) (Min) @ Ic, Vce: -
- Power - Max: 60W
- Frequency - Transition: -
- Operating Temperature: 150°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-220-3
- Supplier Device Package: TO-220-3
- Base Part Number: BU806
