دیتاشیت TIP115

TIP110-112,115-117

مشخصات دیتاشیت

نام دیتاشیت TIP110-112,115-117
حجم فایل 146.234 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت TIP110-112,115-117

TIP110-112,115-117 Datasheet

مشخصات

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/Darlington Transistors
  • Datasheet: STMicroelectronics TIP115
  • Transistor Type: PNP
  • Operating Temperature: +150°C@(Tj)
  • Collector Current (Ic): 2A
  • Power Dissipation (Pd): 2W
  • Transition frequency (fT): -
  • DC current gain (hFE@Vce,Ic): 1000@4V,1A
  • Collector-emitter voltage (Vceo): 60V
  • Collector cut-off current (Icbo@Vcb): 2mA
  • Collector-emitter saturation voltage (VCE(sat)@Ic,Ib): 2.5V@2A,8mA
  • Package: TO-220
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Bulk
  • Part Status: Obsolete
  • Current - Collector (Ic) (Max): 2A
  • Voltage - Collector Emitter Breakdown (Max): 60V
  • Vce Saturation (Max) @ Ib, Ic: 2.5V @ 8mA, 2A
  • Current - Collector Cutoff (Max): 2mA
  • DC Current Gain (hFE) (Min) @ Ic, Vce: 1000 @ 1A, 4V
  • Power - Max: 2W
  • Frequency - Transition: -
  • Mounting Type: Through Hole
  • Package / Case: TO-220-3
  • Supplier Device Package: TO-220-3
  • Base Part Number: TIP115
