دیتاشیت MC14016BD

MC14016B

مشخصات دیتاشیت

نام دیتاشیت MC14016B
حجم فایل 141.477 کیلوبایت
نوع فایل pdf
تعداد صفحات 10

دانلود دیتاشیت MC14016B

MC14016B Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Switch Circuit: SPST - NO
  • Multiplexer/Demultiplexer Circuit: 1:1
  • Number of Circuits: 4
  • On-State Resistance (Max): 400Ohm
  • Channel-to-Channel Matching (ΔRon): 10Ohm
  • Voltage - Supply, Single (V+): 3V ~ 18V
  • Voltage - Supply, Dual (V±): -
  • Switch Time (Ton, Toff) (Max): -
  • -3db Bandwidth: 37MHz
  • Charge Injection: -
  • Channel Capacitance (CS(off), CD(off)): 5pF
  • Current - Leakage (IS(off)) (Max): 100nA
  • Crosstalk: -80dB @ 1MHz
  • Operating Temperature: -55°C ~ 125°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 14-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 14-SOIC
  • Base Part Number: MC14016
