KSH50TF دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
KSH50TF
|
|
حجم فایل
|
304.006
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
2
|
مشخصات فنی
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
Transistor Type:
NPN
-
Current - Collector (Ic) (Max):
1A
-
Voltage - Collector Emitter Breakdown (Max):
400V
-
Vce Saturation (Max) @ Ib, Ic:
1V @ 200mA, 1A
-
Current - Collector Cutoff (Max):
200µA
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
30 @ 300mA, 10V
-
Power - Max:
1.56W
-
Frequency - Transition:
10MHz
-
Operating Temperature:
150°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-252-3, DPak (2 Leads + Tab), SC-63
-
Supplier Device Package:
TO-252, (D-Pak)
-
Base Part Number:
KSH50
-
detail:
Bipolar (BJT) Transistor NPN 400V 1A 10MHz 1.56W Surface Mount TO-252, (D-Pak)
