دیتاشیت BCP69
مشخصات دیتاشیت
| نام دیتاشیت |
BCP69
|
| حجم فایل |
50.268
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
8
|
مشخصات
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
Transistor Type:
PNP
-
Current - Collector (Ic) (Max):
1.5A
-
Voltage - Collector Emitter Breakdown (Max):
20V
-
Vce Saturation (Max) @ Ib, Ic:
500mV @ 100mA, 1A
-
Current - Collector Cutoff (Max):
100nA (ICBO)
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
85 @ 500mA, 1V
-
Power - Max:
1W
-
Frequency - Transition:
-
-
Operating Temperature:
150°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-261-4, TO-261AA
-
Supplier Device Package:
SOT-223-4
-
Base Part Number:
BCP69
