دیتاشیت BAS19
مشخصات دیتاشیت
| نام دیتاشیت |
BAS19
|
| حجم فایل |
179.273
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
3
|
مشخصات
-
RoHS:
true
-
Category:
Diodes/Switching Diode
-
Datasheet:
Jiangsu Changjing Electronics Technology Co., Ltd. BAS19
-
Power Dissipation:
250mW
-
Diode Configuration:
Single
-
Reverse Voltage (Vr):
120V
-
Operating Temperature:
+150°C@(Tj)
-
Forward Voltage (Vf@If):
1.25V@200mA
-
Reverse Leakage Current:
100nA@100V
-
Reverse Recovery Time (trr):
50ns
-
Average Rectified Current (Io):
200mA
-
Package:
SOT-23
-
Manufacturer:
Jiangsu Changjing Electronics Technology Co., Ltd.
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
Diode Type:
Standard
-
Voltage - DC Reverse (Vr) (Max):
120V
-
Current - Average Rectified (Io):
200mA
-
Voltage - Forward (Vf) (Max) @ If:
1.25V @ 200mA
-
Speed:
Small Signal =< 200mA (Io), Any Speed
-
Current - Reverse Leakage @ Vr:
100nA @ 100V
-
Capacitance @ Vr, F:
5pF @ 0V, 1MHz
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-236-3, SC-59, SOT-23-3
-
Supplier Device Package:
SOT-23-3 (TO-236)
-
Operating Temperature - Junction:
-55°C ~ 150°C
-
Base Part Number:
BAS19
