دیتاشیت 1N4148WT

1N4148WT, 1N4448WT, 1N914BWT Datasheet

مشخصات دیتاشیت

نام دیتاشیت 1N4148WT, 1N4448WT, 1N914BWT Datasheet
حجم فایل 299.533 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت 1N4148WT, 1N4448WT, 1N914BWT Datasheet

1N4148WT, 1N4448WT, 1N914BWT Datasheet Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Switching Diode
  • Datasheet: onsemi 1N4148WT
  • Power Dissipation: 200mW
  • Diode Configuration: Single
  • Reverse Voltage (Vr): 75V
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Forward Voltage (Vf@If): 1V@10mA
  • Reverse Leakage Current: 5uA@75V
  • Reverse Recovery Time (trr): 4ns
  • Average Rectified Current (Io): 300mA
  • Package: SOD-523F
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 75V
  • Current - Average Rectified (Io): 200mA
  • Voltage - Forward (Vf) (Max) @ If: 1V @ 10mA
  • Speed: Small Signal =< 200mA (Io), Any Speed
  • Current - Reverse Leakage @ Vr: 5µA @ 75V
  • Capacitance @ Vr, F: 5pF @ 0V, 1MHz
  • Mounting Type: Surface Mount
  • Package / Case: SC-79, SOD-523F
  • Supplier Device Package: SOD-523F
  • Operating Temperature - Junction: -55°C ~ 150°C
  • Base Part Number: 1N4148
  • detail: Diode Standard 75V 200mA Surface Mount SOD-523F
